Aten CS1742 2-Port USB Dual-View KVMP Switch

CS1742 2 Port KVM Switch integrates functions of video signal dual output and USB KVM switches. It allows a computer with dual-screen support to pair with two VGA/SVGA/Multisync displays via a USB keyboard and mouse. Furthermore, CS1742 provides 2 USB ports, allowing each server to share any USB peripheral device that is connected to this HUB.

Features

• Allows one USB keyboard, USB mouse, speakers, microphone and two displays to control four dual display computers
• 2 port USB Hub built in
• Multiplatform support: compatible with all operation platforms PC (Windows, Linux and most others), Mac and Sun
• With speaker and microphone support
• Bi-directional switching and flexible interoperability; switch permits independent PC, independent peripheral, and independent audio function, regardless of KVM switch focus
• Buzzer On/Off via hotkey
• Keyboard and mouse emulation for error free booting
• Computer selection via front panel pushbuttons and hotkeys
• Superior video quality - up to 2048 x 1536; DDC2B
• Firmware upgradeable
• OS Support:Windows 2000, Windows XP, Windows Vista, LINUX, Mac, Sun and FreeBSD
• SUN/Mac keyboard support and emulation: (1.PC keyboard combinations emulate SUN/Mac keyboards, 2.SUN/Mac keyboards only work with their own computers)
• Connectors: USB Hub - 2 x USB Type A Female (White)
• Housing: Metal

Specifications

Electrical
Power Adaptor Output	5VDC
Environmental
Operating Temperature	Operating Temperature 0 to 50�C
Operating Humidity	Humidity 0 to 80%
General
Model Name	CS1742
Product Type	KVM Switch
Barcode	4710423773080
Input
Control Buttons	Push Button Hotkeys
Interfaces/Ports
Console Keyboard Port	1 x USB Type A Female (White)
Console Mouse Port	1 x USB Type A Female (White)
Console Audio Port	1 x Mini Stereo Jack Female (Green)
Console Microphone Port	1 x Mini Stereo Jack Female (Pink)
Video In Ports	2 x HDB-15 Female (Blue)
KVM Ports & Connectors	Speaker/Microphone: 2 x SPHD-15 Male (Yellow), Keyboard/Mouse: 2 x SPHD-15 Female (Green)
RJ-45 Ports	1 x RJ-45 Female (Black)
DC Power	1 x DC Jack (Black)
Physical
LED Status Indicators	On Line/ Selected: 2 (Orange), USB Link: 2 (Green)
In The Box	1x 2-Port USB Dual-View KVMP Switch � 4x KVM Cables � 1x Firmware Upgrade Cable � 1x User Manual � 1x Quick Start Guide
Dimensions	21.00cm (W) x 8.70cm (D) x 5.50cm (H) - Weight 0.82kg
System Requirements
Operating Systems Supported	Windows 2000, XP, Vista, Linux, Mac, Sun, FreeBSD
