Aten CE100 Mini USB KVM Extender (Black)

The CE100 USB KVM Extender with superior video quality and built-in ESD protection allows access to a computer system from a remote USB console (USB keyboard, USB mouse, and monitor). The CE100 improves on previous designs by: 1) incorporating a compensation adjustment function at the Remote unit for greater video quality; and 2) using inexpensive Cat 5e cable, instead of bulky, expensive, standard cables, to provide a neater, more convenient, more reliable data transfer connection.

Features

• Extends local PC VGA/keyboard/Mouse to Remote side
• Uses Cat 5e cable to connect the local and remote units
• Easily add or remove computers connected to the installation
• Supports real time DDC communication
• Superior video quality - up to 1920 x 1200
• Allow access to a computer from the remote console up to 100 m distance
• Support manual compensation adjustment for better video quality
• No external power supply needed for local unit
• Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
• Wall mountable

Specifications

Display
Monitor Resolution Support	1280 x 1024 Pixels
Resolution (Maximum)	1920 x 1200dpi
Electrical
Power Adaptor Output	5VDC
Environmental
Operating Temperature	Operating Temperature 0 to 50�C
Operating Humidity	Humidity 0 to 80%
General
Model Name	CE100
Product Type	KVM Extender
Barcode	4710423773462
Input
Status Indicators	LED
Interfaces/Ports
PC USB Port(s)	1 x USB
Console Keyboard Port	1 x USB Type A Female (White)
Console Mouse Port	1 x USB Type A Female (White)
Console Monitor Port	1 x HDB-15 Female (Blue)
Video In Ports	1 x HDB-15 Male (Blue)
RJ-45 Ports	1 x RJ-45 Female
DC Power	1 x DC Jack
Physical
LED Status Indicators	1 - Link � 1 - Power
Case Colour	Black
In The Box	1 x CE100L Mini USB KVM Extender (Local Unit); 1 x CE100R Mini USB KVM Extender (Remote Unit); 1 x USB/VGA Cable; 2 x Grounding Wires; 1 x Power Adaptor (for Remote Unit); 1 x Wall Mount Kit; 1 x User Guide
Dimensions	5.5cm (W) x 9.0cm (D) x 2.4cm (H) - Weight 0.16kg
