Intel� Nuc DC53427HYE Intel� Core i5 (3427U) 1.8GHz Intel Chipset (Black and Grey)
BOXDC53427HYEPlease contact us to discuss alternative products which may be suitable.
Imagine a computing device powerful enough to produce stunning visuals with responsive performance. Yet small enough to drive digital signage kiosks or other applications demanding performance in a tight space. We did. The result is the Intel Next Unit of Computing (NUC). With a visibly smart Intel Core i3 processor in a highly customizable package the NUC is a breakthrough in compact but impactful computing. Drive two digital displays at once with dual HDMI. Get reliable connectivity through Gigabit LAN. Effortlessly move between applications with smart multitasking delivered by Intel Hyper-Threading Technology.
Specifications
| CPU | |
| Processor | Intel Core i5 ( 3427U ) 1.8 GHz (L1 Cache) (L2 Cache) 3 MB (L3 Cache) |
| CPU Bus Speed | |
| Socket | |
| Package | |
| Supported Processors | |
| Motherboard | |
| Motherboard | |
| Chipset | Intel QS77 Express |
| Processors (Max) | 1 (1) |
| Maximum Bus Speed | |
| PCI 32 bit | |
| PCI 64 bit | |
| PCI Express Slot | 1 x Mini-PCI Express (Full Length) Slot • 1 x Mini-PCI Express (Half Length) Slots |
| ExpressCard Slot | |
| PC Card | |
| AGP Slot | |
| Expansion Slots | |
| Hard Disk Interface | |
| Integrated Network | Yes |
| Integrated WLAN | |
| Integrated Graphics | Yes , Intel HD Graphics 4000 , (Total Graphics Memory) (Integrated Graphics Memory) |
| Integrated Bluetooth | |
| Integrated Sound | |
| Integrated Modem | |
| Memory | |
| Memory (Maximum) | ( 16384 MB ) 1066/1333/1600 MHz DDR3 |
| Memory Slot | 2 x SODIMM |
| Storage | |
| Hard Disk | ( x ) Hard Drive |
| Removable Hard Disk | |
| Solid State Storage | |
| RAID Format | |
| Maximum Internal Storage | |
| Internal Expansion Bays | |
| External Expansion Bays | |
| Multi-Purpose Bay | |
| Floppy Disk Drive | |
| Display | |
| Display Included | |
| Display Integrated | |
| Display Model | |
| Display Case Colour | |
| Flat Panel Display | |
| Touchscreen | |
| Contrast Ratio | (Static) (Dynamic) |
| Aspect Ratio | |
| Response time | |
| Brightness | |
| Display Warranty | |
| CRT Monitor | ( Viewable) Dot Pitch |
| Graphics Card | |
| Graphics Form Factor | |
| Graphics Device | |
| Video Card Bus Type | |
| Video Card Maximum Resolution | |
| Graphics Features | |
| Optical Drive | |
| Optical Drive Type | |
| LightScribe | |
| Multi-media Features | |
| Optical Drive 2 Type | |
| LightScribe Drive 2 | |
| Multi-media Features Drive 2 | |
| Input | |
| Keyboard | |
| Pointing Device | |
| Remote Control | |
| Sound | |
| Sound Card | Intel High Definition Audio (Intel HD Audio) |
| Sound Card Interface | |
| Speakers | |
| 3D Direct Sound Support | |
| Audio Features | |
| Interfaces/Ports | |
| RJ-45 Ports | 1 x RJ-45 |
| DVI Out | |
| HDMI Port | 1 x HDMI |
| DisplayPort | 2 x Mini DisplayPort |
| Thunderbolt Port(s) | |
| VGA Port | |
| USB Ports | 4 x USB 2.0 • 1 x USB 3.0 |
| eSATA Port | |
| Video Composite In | |
| Video Composite Out | |
| Video Component Out | |
| Apple Display Connector (ADC) | |
| TV Out | |
| IEEE 1394 (Firewire) Port | |
| S/PDIF Port | |
| S-Video Port | |
| Audio Line In Ports | |
| Audio Line Out Ports | 8 x Line Out (7.1 Digital Audio) |
| Audio/Visual Port | |
| Digital Audio Out | |
| Headphone Ports | |
| Microphone In Port | |
| Optical/Toslink Port | |
| Modem Port | |
| Keyboard Port | |
| Mouse Port | |
| Infrared Port | |
| Serial Ports | |
| Parallel Ports | |
| Co-Axial Port | |
| SCART Ports | |
| Game/ Midi Ports | |
| TV Input | |
| AC Power | |
| DC Power | |
| Media Adaptor | |
| Removable Flash Memory Adaptor | |
| Number of Card Slots | |
| Number of Card Types Supported | |
| Compact Flash | |
| Smart Media | |
| MultiMedia Card | |
| Sony Memory Stick | |
| Secure Digital | |
| xD-Picture Card | |
| Micro Drive | |
| Transflash | |
| Magicstor Drive | |
| Smart Card Reader | |
| Network | |
| Wired Network | Yes |
| Network Interface | Intel PRO Gigabit Ethernet 10/100/1000 Mbps Integrated |
| Wireless Network | |
| Wireless LAN | |
| Bluetooth | |
| Modem | |
| Modem | |
| Data Modes | |
| Fax Modes | |
| Fax Speed | |
| TV Tuner | |
| TV Tuner Type | |
| TV Antenna | |
| Camera | |
| Webcam | |
| Camera Resolution | |
| Effective Pixel Resolution | |
| Camera Features | |
| Compliance | |
| EMI | |
| Safety | |
| Certifications | |
| System | |
| Software Included | |
| Plug and Play | |
| Management | 128Mb Flash EEPROM with Intel Platform Innovation Framework for EFI Plug and Play • Advanced configuration and power interface V3.0b, SMBIOS2.5 • Intel Express BIOS update support • Optimized POST for almost instant-on accessto PC from power on |
| Security | |
| Operating System | |
| System Requirements | |
| Operating Systems Supported | |
| Electrical | |
| Electrical Power Available | 65 W |
| Voltage/Power/Frequency | / / |
| Power Cord | |
| Environmental | |
| Environmental | Operating Temperature 0 to 55 °C - Humidity |
| Noise Level (full operating mode) | |
| Physical | |
| Form Factor | Ultra Compact Form Factor (UCFF) |
| LED Status Indicators | HDD LED, Power LED, Power on/off |
| Case Colour | Black |
| In The Box | |
| Security Locking Mechanics | |
| Dimensions | 11.2 cm (W) x 3.9 cm (D) x 11.66 cm (H) - Weight |
For further related products such as Intels Recommended MSata drives for this model please see the related product list.
Customer Reviews
There are currently no reviews against this product. Be the first to write a review!
Write a Review
Sorry there are no compatible products listed. Please contact us to discuss options available for this product.
Product downloads
Please see below our available downloads for this product. If there is a download that isn't listed please contact us. Please also have a look at our Installation/Setup Instructions page.
