Huawei AR2220 Basic Configuration Enterprise Network Router - 2 x GE WAN,1 x GE Combo WAN, 2 x USB, 2GB MicroSD, 4 x SIC Slots, 2 x WSIC Slots,1 x DSP

The AR2200 uses the embedded hardware encryption technique and supports the voice Digital Signal Processor (DSP). It supports firewall functions, call processing, voice mail, and various application programs.The AR2200 supports various wired and wireless access modes, such as E1/T1, xDSL, xPON, CPOS and 3G.The AR2200 series include: AR2220 and AR2240.



The AR2200 uses the multi-core CPU and non-blocking switching structure and provides industry-leading system performance, meeting network extension requirements and service development requirements of enterprises.� Multi-core CPU The multi-core CPU improves the speed of concurrent processing of data and voice services, which makes it possible to deploy a large number of services.� Non-blocking switching for service traffic The bus channel bandwidth of single slot is up to 10 Gbit/s.� Independent protocol management, service processing, and data switching, ensuring high performance and improving service reliability� Integrated routing and switching functions This feature improves the data switching efficiency between interface cards and simplifies device configurations and maintenance.� Hot swappable interface cards and redundant components such as fan modules and power modules ensuring service reliability and stabilityFeatures

• Forwarding capacity: 1Mpps
• WAN speed with services: 400Mbps
• Fixed port: 3GE (one combo port)
• Slot: 4SIC + 2WSIC
• Dimensions (WxDxH): 442 mm x 420 mm x 44.5 mm
• 3rd Generation AR with Industry-Leading Performance
• Dual-Mode Network, Supporting Flexible Access
• Services Integrated on One Router

Specifications

Electrical
Voltage/Power/Frequency	100 to 240VAC / 50 to 60Hz
Environmental
Environmental	Humidity 5 to 90% Operating Temperature 0 to 40�C
Ethernet
Protocols Supported	IEEE 802.1P, IEEE 802.1Q, IEEE 802.3, VLAN management, MAC address management, MSTP
Ethernet Standards	Routing policy, static route, RIP, OSPF, IS-IS, BGP
General
Model Name	AR2220-AC
Product Family	AR2200
Product Type	Network Router
Barcode	6920702722830
Interfaces/Ports
LAN Ports	4 port(s) x RJ-45
USB Ports	2 x USB
Memory
Memory (Maximum)	2048MB
Physical
In The Box	AR2220 Chassis,150W AC Power with Basic Software and Documentation
Dimensions	44.5cm (W) x 44.2cm (D) x 42.0cm (H)
Security
Security	ACL, firewall, 802.1x authentication, MAC address authentication, Web authentication, AAA authentication, RADIUS authentication, HWTACACS authentication, broadcast storm suppression, ARP security, ICMP attack defense, URPF, IP Source Guard, DHCP snooping, CPCAR, blacklist, IP source tracing
System
Management	Upgrade management, device management, GTL, SNMP(v1/v2c/v3), NTP, CWMP, Auto-Config, deployment using USB disk, NetConf, CLI
