Netgear GS748TP ProSafe 48 Port 10/100/1000 Smart PoE Switch

NETGEAR ProSafe Smart Switches fill the gap between unmanaged and fully managed switches. The family of ProSafe Smart Switches is designed for growing businesses that want control over their network without the cost and complexity of a full Layer 2 management implementation. This PoE capable Smart Switch (GS748TP), provide power and data using built-in IEEE 802.3af PoE on all 48 ports. In addition, they offer an intuitive webbased management tool for quick and easy deployment and configuration making it ideal for deploying access points, VoIP phones and IP-based surveillance cameras. This switch is equipped with highly advanced features such as Access Control Lists (ACL), 802.1x port authentication, enhanced QoS, rate limiting and IGMP Snooping among others to provide a small and medium-sized business with a network that is geared for growth while providing scalability and reliability. With the utility of 48 10/100/1000 Mbps ports, four combination (Copper/hot-swappable Small Form-factor Pluggable (SFP)) Gigabit ports for optional fibre connectivity, growing business networks, classrooms and workgroups can benefit from superior performance and keep up with expanding network needs. These high performing switches feature a nonblocking wire-speed architecture with 96 Gbps switching capacity for maximum data throughput.

Features

• Network Ports: 48 10/100/1000 Mbps auto-sensing Gigabit Ethernet, 4 combo Gigabit copper/SFP slots
• Buffer memory: 3 Mb per system
• Bandwidth: 96 Gbps
• Modules: AGM731F 1000BASE-SX SFP Module, AGM732F 1000BASE-LX SFP Module, AGM733 1000BASE-LZ SFP Module
• Address database size: 4,000 media access control (MAC) addresses per system
• Operating altitude: 10,000 ft (3,000 m) maximum
• Storage altitude: 10,000 ft (3,000 m) maximum
• Advanced features: 802.1x, ACLs, Rate limiting, DSCP/TOS-based prioritization, IGMP Snooping, SNMP v1, v2, v3, RSTP
• Total PoE budget is 384 Watts

Specifications

Compliance
Standards Compliance	IEEE 802.3 10BASE-T � IEEE 802.3u 100BASE-TX � IEEE 802.3ab 1000BASE-T � IEEE 802.3z 1000BASE-X � IEEE 802.3x full-duplex flow control � IEEE 802.3af (Power over Ethernet)
Electrical
Voltage/Power/Frequency	100 to 240VAC / 50 to 60Hz
Power Cord	UK Country Specific
Environmental
Noise Level (full operating mode)	44.8dbA
Environmental	Operating Temperature 0 to 50�C - Humidity 0 to 90%
General
Model Name	GS748TP
Product Type	Network Switch
Warranty	Netgear Lifetime Warranty
Barcode	5051749447750
Interfaces/Ports
Network Speeds Supported	10/100/1000MBps
Power over Ethernet (PoE)	Yes , 384W
Fixed Ports	48 port(s) x 10/100/1000Mbps ,
Memory
Buffer Memory	3MB
Performance
Mean Time Between Failure (MTBF)	147, 559 Hours
Network Latency	<2,900 ns for 64-byte frames in store-and-forward mode for 1,000 Mbps to 1,000 Mbps transmission
Physical
LED Status Indicators	Per port: (10/100 and Gigabit): Link/ Activity, Speed � Per device: Power � Per device: Fan failure � Per PoE ports: Poe power, PoE fault
In The Box	48-port Smart Switch with � Gigabit Ports and PoE (GS748TP) � Rubber footpads � Power cord � Rack-mount kit � Resource CD � Installation guide � Warranty/support information card
Dimensions	44.0cm (W) x 43.8cm (D) x 4.3cm (H) - Weight 6.6kg
System
Management Capabilities	IEEE 802.1Q static VLAN (128 groups, static) � Voice VLAN � IEEE 802.1p Class of Service (CoS) � Port-based QoS � DSCP-based QoS � IEEE802.3ad link aggregation (manual or LACP) � IEEE 802.1D Spanning Tree Protocol � IEEE 802.1w Rapid Spanning � Tree Protocol � SNMP v1, v2c, v3 � RFC 1213 MIB II � RFC 1643 Ethernet interface MIB � RFC 1493 bridge MIB � RMON group 1, 2, 3, 9 � RFC 2131 DHCP client � IEEE 802.1x � Jumbo frame support � Port-based security by locked � MAC addresses � Layers 2-4 based ACL � Storm control for broadcast, multicast and unknown unicast packets � IGMP snooping v1/v2 � Port-based ingress rate limiting � SNTP � Port mirroring support (many to one) � Web-based configuration � Configuration backup/restore � Password access control � RADIUS support � TACACS+ support � Syslog � Firmware upgradeable
Certifications	CE mark, commercial � FCC Part 15 Class A � VCCI Class A � C-Tick � cUL IEC950/EN60950
System Requirements
System Requirements	Category 5 network cables � Network card for each PC � Network software (e.g., Windows) � Web browser (e.g., Internet Explorer � 5.0 or higher, Netscape 6.0 or higher)
