System | |
Form Factor | 1U |
Dimensions | 660.4 x 438.0 x 43.5 mm (26'' x 17.2'' x 1.7'') |
Support MB | X570D4U-2L2T |
Front Panel | |
Buttons | Reset, Power w/ LED, UID w/ LED |
LEDs | System Fail, LAN1, LAN2 |
I/O Ports | 2 RJ45(10GbE), 2 RJ45 (1GbE) 2 Type A (USB3.2 Gen1) 1 DB15 (VGA), 1 HDMI 1 DB9 (COM) |
IPMI LAN | 1 dedicated IPMI |
External Drive Bay / Storage | |
Rear Side | 2 SFF 2.5”(SATA 6Gb/s) |
Internal Side | 1 M-key (PCIe4.0* x4 or SATA 6Gb/s); Form factor: 22110/2280/2260/2242 [CPU] 1 M-key (PCIe4.0* x4 or SATA 6Gb/s); Form factor: 2280/2260/2242 [FCH] *Supports PCIe3.0 when using AMD Ryzen™ 4000 and 3000 G-Series Desktop Processors with Radeon™ Graphics |
Power Supply | |
Type | 1+1 CRPS |
Output Watts | 800W |
Efficiency | 80-PLUS Platinum |
AC Input | 100-240V, 50/60Hz |
System Fan | |
Fan | 6 single-rotor 40x56 mm fans |
Processor System | |
CPU | Supports: AMD Ryzen™ 5000 and 3000 Series Desktop Processors AMD Ryzen™ 4000 and 3000 G-Series Desktop Processors with Radeon™ Graphics AMD Ryzen™ PRO 5000, 4000 and 3000 Series Desktop Processors |
Socket | AM4 PGA 1331 |
Chipset | AMD X570 |
System Memory | |
Supported DIMM Quantity | 4 DIMM slots (2DPC) |
Supported Type | Supports DDR4 288-pin ECC*/non-ECC UDIMM *For AMD Ryzen Desktop Processors with Radeon Graphics, ECC support is only with Processors with PRO technologies. |
Max. Capacity per DIMM | up to 32GB per DIMM |
Max. DIMM Frequency | up to 3200 MHz* * AMD Ryzen™ 3000 G-Series Desktop Processors with Radeon™ Graphics support up to 2666 MHz |
Voltage | 1.2V |
PCIe Expansion Slots (SLOT7 close to CPU) | |
PCIe x 16 | Supports 1 FH dual-slot PCIe4.0 x16* via 1U4G_ROME_R_RDV *Supports PCIe3.0 x8 when using AMD Ryzen™ 3000 G-Series Desktop Processors with Radeon™ Graphics *Supports PCIe3.0 x16 when using AMD Ryzen™ 4000 G-Series Desktop Processors with Radeon™ Graphics |
Ethernet | |
Additional GbE Controller | Intel® X550-AT2: 2 RJ45 (10GbE) 2 Intel® i210: 2 RJ45 (1GbE) |
Server Management | |
BMC Controller | ASPEED AST2500 |
IPMI Dedicated GLAN | 1 RJ45 via Realtek RTL8211E |
Rear I/O | |
USB 3.2 Gen1 Port | 2 Type-A (USB3.2 Gen1) |
System BIOS | |
BIOS Type | 256Mb AMI UEFI Legal BIOS |
BIOS Features | Plug and Play (PnP), ACPI 2.0 Compliance Wake Up Events, SMBIOS 2.8.0 Support, ASRock Rack Instant Flash |
Environment | |
Temperature | Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
Humidity | Non operation humidity: 20% ~ 90% ( Non condensing) |
