ASRock Rack 1U2N2G-AM5/2T 1U Rackmount Server Barebone - Dual Node AMD EPYC 4004 Series CPU - GPU Support - Dual PSU
1U2N2G-AM5-2T
ASRock Rack 1U2N2G-AM5/2T 1U Rackmount Server Barebone - Dual Node AMD EPYC 4004 Series CPU - GPU Support - Dual PSU
Call our Solutions Specialists - 01283 576162
Great news, we have this product available for special order on a 5 day lead time.
To learn more about this product complete the form below and one of our team will get right back to you.
Product Description
| System | |
| Form Factor | 1U Rackmount |
| Dimensions | 650 x 438 x 43.5 mm (25.6'' x 17.2'' x 1.7'') |
| Support MB | AM5D4ID-2T/BCM |
| Front Panel | |
| Buttons | UID w/LED, Power w/LED |
| LEDs | System Fail |
| I/O Ports | 2 RJ45 (10GbE) by Broadcom BCM57416, 2 Type-A (USB3.2 Gen1), 1 DB15 (VGA), 1 HDMI |
| IPMI LAN | 1 dedicated IPMI |
| External Drive Bay / Storage | |
| Internal Side | 1 M-key (PCIe4.0 x4), supports 2280 form factor [CPU] |
| Power Supply | |
| Type | 1+1 CRPS |
| Output Watts | 1000W @100-127Vac input / 1600W @200-240Vac input |
| Efficiency | 80-PLUS Platinum |
| AC Input | Low-line: 100-127Vac, 60/50Hz; High-line: 200-240Vac, 60/50Hz |
| System Fan | |
| Fan | 8 PWM Hot-swap 40x56 mm fans |
| Processor System | |
| CPU | Supports AMD EPYC™ 4004 and AMD Ryzen™ 8000/7000 Series Processors |
| Socket | Single Socket AM5 (LGA 1718) |
| Thermal Design Power | Up to 120W |
| Chipset | KNOLL3 X300 |
| System Memory | |
| Supported DIMM Quantity | 4 DIMM slots (2DPC) |
| Supported Type | DDR5 288-pin ECC/non-ECC UDIMM |
| Max. Capacity per DIMM | 48GB |
| Max. DIMM Frequency | 5200 MHz (1DPC); 3600 MHz (2DPC) |
| Voltage | 1.1V |
| PCIe Expansion Slots (SLOT7 close to CPU) | |
| PCIe x 16 | 1 FH dual-slot PCIe5.0 x16 |
| Ethernet | |
| Additional GbE Controller | Broadcom BCM57416: 2 RJ45 (10GbE) |
| Server Management | |
| BMC Controller | ASPEED AST2600 |
| IPMI Dedicated GLAN | 1 Realtek RTL8211F for dedicated management GLAN |
| Graphics | |
| Controller | ASPEED AST2600: 1 DB15 (VGA) AMD Processors with Graphics: 1 HDMI |
| System BIOS | |
| BIOS Type | AMI UEFI BIOS; 256Mb (32MB) SPI Flash ROM |
| BIOS Features | Plug and Play, ACPI 5.1 compliance wake up events, SMBIOS 2.3 |
| Hardware Monitor | |
| Temperature | CPU, DDR, MB, Card Side |
| Fan | Fan Tachometer, Multi-Speed Control, CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) |
| Voltage | 3VSB, 5VSB, VCPU, VCCM, APU VDDP, 1.05V_PROM_S5, 2.5V_PROM, 1.05V_PROM_RUN, BAT, 3V, 5V, 12V |
| Supported OS | |
| OS | Microsoft® Windows: Windows® 10 (64 bit) Windows® 11 (64 bit) Linux: UBuntu 22.04.2 (64 bit) * On the Windows® system, Raid mode supports UEFI Boot only. * The Linux system doesn't support Raid Mode. |
| Environment | |
| Temperature | Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
| Humidity | Non operation humidity: 20% ~ 90% ( Non condensing) |
