1U 12G Storage Server Chassis 12 x 3.5" + 2 x 2.5" 7mm Internal High Density Server with 600W redundant Platinum PSU

RSC-1C-BAR6

£1,045.20

ex. VAT

(£1,254.24

inc. VAT)

This product is currently out of stock.
Call/Email/Live Chat our sales team for availability, we look forward to hearing from you.

Looking for Compatible Products?

Key features

• High-density design for space saving (cost saving)
• 1 drawer to load up to 12 hot swap drives
• Tool-less design supports quick installation and easy maintenance:
- Tool-less 3.5” drive trays
- Tool-less top covers
• Anti-vibration rubbers on drive trays and fans
• Silicon gaskets to absorb vibration from sides of drives
• Easy swap system fans designed to minimize rotational vibration while providing superior cooling

Features And Benifits

As the manager or operator of a data center, it is important to maintain tight control over costs while providing the maximum uptime for your customers. For that reason, AIC has developed the RSC-1C, a 1U 12-Bay storage server chassis. It enables data center services companies that run object storage applications a more efficient and economical solution. If you run Ceph, the RSC-1C is designed to provide abundant storage space and support for computing power to meet shifting application requirements. The tool-less design makes installation and maintenance quick and easy. Rubbers on the drive tray and silicon gaskets protect against vibrations. Its high-density, space-saving design saves you money. Its drives can be hot swapped at a moment’s notice, resulting in less downtime. (Power supply is included. Motherboard is not included.)

Dimensions (W x D x H) (with chassis ears)
• mm : 483 x 910 x 44
• inches : 19 x 35.8 x 1.73

Industry Standard
EIA-RS310D

Material
Heavy-duty preplated SPGC cold-rolled steel

Color
Not coated

Cooling
Middle : 5 x 40x28mm PWM easy swap fans

Power Supply
520W single PSU PMBus 1.2 80+ Platinum

Expansion Slot
1 full height via riser card (Please see Optional Product for details)

Front Panel
• Power on/off
• System reset

LED Indicators
• Power
• LAN
• Drive

System Board
12”(W) x 9.6”(D) ATX

Drive Bays
Internal : 12 x 3.5” hot swap & 2 x 2.5”

Backplanes
3 x 4-port 12Gb SAS backplanes with single SFF-8643 connector on each

Storage Temperature
0°C(32°F) ~ 50°C(122°F)

Humidity
5% ~ 95% non-condensing

Gross Weight (w/ PSU & Rail)
• kgs : 25
• lbs : 55.1

Package Dimension (W x D x H)
• mm : 600 x 1085 x 208
• inches : 23.6 x 42.7 x 8.2

Cubic Feet
4.8

Container Load Quantity
• 20’ : 198
• 40’ : 418
• 40’ H : 456

Mounting
Standard : 26” tool-less slide rail

Reviews

Customer Reviews

There are currently no reviews against this product. Be the first to write a review!

Write a Review

Name *

Email *

Your Rating

Your Review*

Compatible Products

Sorry there are no compatible products listed. Please contact us to discuss options available for this product.

Downloads

Product downloads

There are currently no downloads available for this product. If you need a specific document, such as a manual, installation guide or datasheet please contact us and we would be happy to help.
