Features
Supporting Boxee
Play All Media Content Stored on NAS
Video Output via HDMI
TV Shows, Movies, Apps and More
ASUSTOR Customized Features
AiRemote Mobile App
Hardware Specifications
CPU: Intel® Atom™ 2.13 GHz Dual-Core Processor
Memory: 1GB SO-DIMM DDR3 (Expandable. Max. 3GB)
HDD: 2.5" or 3.5" SATA II/ III x 2¹
Expansion: USB 3.0 x 2, USB 2.0 x 4, eSATA x 2
Network: Gigabit Ethernet x 2
Output: HDMI x 1
System Fan: 70mm x 1
Input Power Voltage: 100V to 240V AC
Certification: FCC, CE, VCCI, BSMI, C-TICK
Operation
Power Consumption: 23.5W (Operation); 19W (Disk Hibernation); 1.4W (Sleep Mode)
Noise Level: 21.3 dB(A)
Operation Temperature: 5°C~35°C (40°F~95°F)
Humidity: 5% to 95% RH
Size and Weight
Size: 163.5(H) x 108(W) x 230(D) mm
Weight: 2.1 kg / 4.63 lb
Eco-Friendly Design
System Sleep Mode (S3)
Auto-Standby for Both Internal and External Disks
Auto Fan Control
LED Night Mode
Power Schedule: On, Off, Restart, and Sleep
Package Contents
AS-602T Unit x1
Installation CD x1
AC Power Cord x1 / AC Power Adapter x1
RJ-45 LAN Cable(Cat 5e) x2
Flat Head Screw (for 3.5" HDD) x8
Flat Head Screw (for 2.5" HDD) x8
Operating System
ADM 1.0 Onwards
Built-in App Central for Various Apps
Supported OS
Windows XP, Vista, 7, Server 2003, Server 2008
Mac OS X 10.4 Onward
UNIX, Linux, and BSD
Supported Languages
Deutsch, Dutch, English, Français, Italiano, Nederlands, ???????, ???, ??, ????, ????
Supported Browsers
Internet Explorer 9
FireFox
Chrome
Safari
Network Protocols
CIFS/SMB, AFP, NFS, FTP, WebDAV, Rsync, SSH, SFTP, iSCSI, HTTP, HTTPS
File System
Internal Disk: EXT4
External Disk: FAT32, NTFS, EXT3, EXT4, HFS+
Storage Management
Volume Type: Single disk, JBOD, RAID 0, RAID 1
Support for Online RAID Level Migration
Support for Online RAID Capacity Expansion
iSCSI
Maximum Targets: 256
Maximum LUNs: 256
Target Masking
LUN Mapping
ISO File Mounting
Supports MPIO & MCS
Persistent (SCSI-3) Reservations
Disk Management
Scheduled Bad Block Scans
Scheduled S.M.A.R.T Scans
Network
TCP/IP (IPv4 & IPv6)
Link Aggregation: Supports 802.3ad and Six Other Modes for Load Balancing and/or Network Failover
Jumbo Frame (MTU)
VLAN
ASUSTOR Cloud Connect
Wireless Network²
DDNS and EZ-Router
Backup Solutions
Rsync (Remote Sync) Backup
Cloud Backup
FTP Backup
External Backup
One Touch Backup
System Administration
Log Type: System Log, Connection Log, File Access Log
Real-time Online User Monitor
Real-time System Monitor
Network Recycle Bin
User Quota
Virtual Drive (ISO Mounting, Maximum 16)
UPS Support
Access Control
Maximum Number of Users: 4096
Maximum Number of Groups: 512
Maximum Number of Shared Folders: 512
Maximum Number of Concurrent Connections: 512
Supports Windows Active Directory
Security
AES 256-Bit Folder Encryption
Firewall: Prevent Unauthorized Access
Network Defender: Prevent Network Attacks
Alert Notifications: E-mail, SMS
Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP, Rsync over SSH
Featured Apps
File Explorer
Web-based File Management
ISO File Mounting
Share Links
Surveillance Center
Live Monitoring (4 Free Channels)
Multiple Channel Playback with Audio
Supported Browsers: Internet Explorer, Chrome, FireFox (Windows only)
Event Notification
UPnP Media Server
Supports PS3 and other Digital Media Player Capable Devices
Supports On-The-Fly Transcoding for Most RAW Images and Audio(OGG, FLAC)
Supported Image Formats: BMP, GIF, ICO, JPG, PNG, PSD, TIF, RAW Image³ (3FR, ARW, CR2, CRW, DCR, DNG, ERF, KDC, MEF, MOS, MRW, NEF, NRW, ORF, PEF, PPM, RAF, RAW, RW2, SR2, X3F)
Supported Audio Formats: 3GP, AAC, AC3, AIFC, AIFF, AMR, APE, AU, AWB, FLAC1, M4A, M4R, MP2, MP3, OGG Vorbis1, PCM, WAV, WMA
Supported Video Formats: 3GP, 3G2, ASF, AVI, DAT, FLV, ISO, M2T, M2V, M2TS, M4V, MKV, MPv4, MPEG1, MPEG2, MPEG4, MTS, MOV, QT, SWF, TP, TRP, TS, VOB, WMV, RMVB, VDR, MPE
iTunes Server
For iTunes on Mac & Windows
Supports AirPlay
Supports iOS Remote Pairing
Supported Audio Formats: AIF4, M4A (AAC & Apple Loseless), M4P, M4R, MP3, WAV4
Supported Video Formats: M4V, MOV, MP4
Supported Playlist Formats: M3U, WPL
Download Center
Supports BT(Torrent & Magnet Link), HTTP and FTP Downloads
Torrent Search
Choose Files Before a BT Task Starts
Customizable Download Schedule
Bandwidth Control
RSS Subscription and Automatic Downloading (Broadcatching)
ASUSTOR Download Assistant for Windows & Mac
AiDownload for iOS & Android
